Range
comprehensive range spanning over 60 models, designed around seven shaft groups, with nominal impeller diameters of 300mm, 360mm, 400mm, 440mm, 540mm & 660mm, meet the standard requirements of all segments. Discharge range extends to 800 l/s with Heads up to 230m at 1450 rpm. Large custom engineered units are also available on request.
Operating Range
Size Range : 50mm(2″) to 400mm(16″)
Capacity & head : up to 3000m3/hr & up to 200m
Materials : Casing : BS 1452 Gr. FG 260 as standard. Other grades SS, Duplex, Bronze available depending on application.
Temp Max : 120 Deg C
Pressure Max : 16 Bar Standard (Up to 25 Bar Max depending on models and Head)
Construction : Single / double volute depending on head. Internal /external cross-over depending on size.
Seals: Soft packed / mech. seal options.
Horizontal/vertical shaft. CW/CCW rotation.
Flange: ANSI/PN/ other Flange options
Applications
Building Services: Condenser and chilled water circulation, fire protection, water transfer.
Utilities: Raw water, clear water, waste water and auxiliary services.
Steel Mills: Service water, roll cooling, blast furnace cooling, cooling tower.
Pulp & paper: Fan pumps, white water, raw water and primary cleaner.
Irrigation: Lift and sprinkler irrigation
General industry: Sugar mills – water supply and spray pond pumps, raw water and cooling water pumps for chemical, petro-chemical and fertilizer industry; mine dewatering pumps.
